WS-C2960X-24TD-L

WS-C2960X-24TD-L

0 Review

List Price:	€3,320.15
Price:	€955.36 (71% OFF)
Condition:	New
Availability:	In Stock
Shipping:	2~6 days Arrival via DHL

Qty:

Estimate Shipping:

Quick Overview

Catalyst 2960 X 24 GigE LAN

Overview
Specification
SMARTnet
Shipping Payment
Warranty
Reviews

Cisco Catalyst 2960-X 24 GigE, 2 x 10G SFP+, LAN Base

Main Specifications
- Bundled Services Limited lifetime warranty
- Product Description Cisco Catalyst 2960X-24TD-L - switch - 24 ports - managed - desktop, rack-mountable
- Manufacturer Warranty Limited lifetime warranty
- Weight 8.8 lbs
- Dimensions (WxDxH) 17.5 in x 11 in x 1.8 in
- Features Layer 2 switching, DHCP support, auto-negotiation, ARP support, trunking, VLAN support, auto-uplink (auto MDI/MDI-X), IPv6 support, Rapid Spanning Tree Protocol (RSTP) support, Multiple Spanning Tree Protocol (MSTP) support, Dynamic Trunking Protocol (DTP) support, Port Aggregation Protocol (PAgP) support, Trivial File Transfer Protocol (TFTP) support, Access Control List (ACL) support, RADIUS support, Jumbo Frames support, MLD snooping, Dynamic ARP Inspection (DAI), Cisco EnergyWise technology, Unicast Reverse Path Forwarding (URPF), Uni-Directional Link Detection (UDLD), Rapid Per-VLAN Spanning Tree Plus (PVRST+), IPv4 support, Shaped Round Robin (SRR), Link Aggregation Control Protocol (LACP), Remote Switch Port Analyzer (RSPAN), NetFlow, Hot Standby Router Protocol (HSRP) support, Energy Efficient Ethernet
- Power AC 120/230 V ( 50/60 Hz )
- Interfaces Gigabit Ethernet
- Ports 24 x 10/100/1000 + 2 x 10 Gigabit SFP+
- Jumbo Frame Support 9216
- Performance Switching capacity : 216 Gbps ¦ Forwarding performance (64-byte packet size) : 95.2 Mpps
- Power Redundancy Optional
- Enclosure Type Desktop, rack-mountable 1U
- Remote Management Protocol SNMP 1, RMON 1, RMON 2, Telnet, SNMP 3, SNMP 2c, HTTP, TFTP, SSH, CLI
- Capacity Virtual interfaces (VLANs) : 1023
- Compliant Standards IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.3ae, IEEE 802.1ae, IEEE 802.3az, IEEE 802.1AX
- Device Type Switch - 24 ports - managed - stackable
- Subtype Gigabit Ethernet
Power
- Power Consumption Operational 24.9 Watt
- Power Redundancy Optional
- Power Redundancy Scheme 1+1 (with optional power supply)
- Voltage Required AC 120/230 V ( 50/60 Hz )
- Power Device Internal power supply
- Installed Qty 1 (installed) / 2 (max)
- Features Redundant Power System (RPS) connector
General
- Max Units In A Stack 8
- Performance Switching capacity : 216 Gbps ¦ Forwarding performance (64-byte packet size) : 95.2 Mpps
- Processor : 600 MHz
- Features Layer 2 switching, DHCP support, auto-negotiation, ARP support, trunking, VLAN support, auto-uplink (auto MDI/MDI-X), IPv6 support, Rapid Spanning Tree Protocol (RSTP) support, Multiple Spanning Tree Protocol (MSTP) support, Dynamic Trunking Protocol (DTP) support, Port Aggregation Protocol (PAgP) support, Trivial File Transfer Protocol (TFTP) support, Access Control List (ACL) support, RADIUS support, Jumbo Frames support, MLD snooping, Dynamic ARP Inspection (DAI), Cisco EnergyWise technology, Unicast Reverse Path Forwarding (URPF), Uni-Directional Link Detection (UDLD), Rapid Per-VLAN Spanning Tree Plus (PVRST+), IPv4 support, Shaped Round Robin (SRR), Link Aggregation Control Protocol (LACP), Remote Switch Port Analyzer (RSPAN), NetFlow, Hot Standby Router Protocol (HSRP) support, Energy Efficient Ethernet
- Status Indicators Link activity, port transmission speed, port duplex mode, system, status
- Enclosure Type Desktop, rack-mountable - 1U
- Device Type Switch - 24 ports - managed - stackable
- Interfaces Gigabit Ethernet
- Compliant Standards IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.3ae, IEEE 802.1ae, IEEE 802.3az, IEEE 802.1AX
- RAM 512 MB
- Remote Management Protocol SNMP 1, RMON 1, RMON 2, Telnet, SNMP 3, SNMP 2c, HTTP, TFTP, SSH, CLI
- Capacity Virtual interfaces (VLANs) : 1023
- Flash Memory 128 MB
- Ports 24 x 10/100/1000 + 2 x 10 Gigabit SFP+
- Jumbo Frame Support 9216
- Authentication Method Kerberos, Secure Shell (SSH), RADIUS, TACACS+
- Subtype Gigabit Ethernet
Dimensions & Weight
- Weight 8.8 lbs
- Height 1.8 in
- Depth 11 in
- Width 17.5 in
Software / System Requirements
- Software Included Cisco IOS LAN Base
Miscellaneous
- Compliant Standards CISPR 22 Class A, CISPR 24, EN 61000-3-2, EN 61000-3-3, EN55024, EN55022 Class A, AS/NZS 60950-1, ICES-003 Class A, RoHS, FCC CFR47 Part 15, EN300-386, UL 60950-1 Second Edition, CSA C22.2 No. 60950-1 Second Edition, EN 60950-1 Second Edition, IEC 60950-1 Second Edition, VCCI Class A, KN22, KN24, CNS 13438(95) Class A
- MTBF 569,520 hours
Manufacturer Warranty
- Service & Support Details Limited warranty - advance parts replacement - lifetime - response time: 10 days ¦ Technical support - consulting - 90 days
- Service & Support Limited lifetime warranty
Environmental Parameters
- Min Storage Temperature -13 °F
- Max Storage Temperature 158 °F
- Humidity Range Storage 10 - 95% (non-condensing)
- Humidity Range Operating 10 - 95% (non-condensing)
- Max Operating Temperature 113 °F
- Min Operating Temperature 23 °F
Expansion / Connectivity
- Interfaces 48 x 10Base-T/100Base-TX/1000Base-T - RJ-45 ¦ 1 x console - RJ-45 - management ¦ 1 x console - mini-USB Type B - management ¦ 1 x USB - Type A ¦ 1 x 10Base-T/100Base-TX - RJ-45 - management ¦ 2 x SFP+
- Expansion Slots 1 (total) / 1 (free) x Stacking Module slot

SMARTnet list

SMARTnet	Description	Price
CON-3SNT-WSC24TDL	3YR SNTC 8X5XNBD Catalyst 2960-X 24 G	Inquiry
CON-SMBS-WSC24TDL	CSCO SUP ESS 8X5XNBD Cat 2960-X 24 GigE, 2 x 10G SFP+, L	Inquiry
CON-SNT-WSC24TDL	SNTC-8X5XNBD Catalyst 2960-X 24 G	Inquiry
CON-SNTE-WSC24TDL	SNTC-8X5X4 Catalyst 2960-X 24 GigE, 2 x 10G SFP+, L	Inquiry
CON-SNTP-WSC24TDL	SNTC-24X7X4 Catalyst 2960-X 24 GigE, 2 x 10G SFP+, L	Inquiry
CON-SSSNP-WSC24TDL	SOLN SUPP 24X7X4 Catalyst 2960-X 24 GigE, 2 x 10G SFP+, LAN	Inquiry
CON-SSSNT-WSC24TDL	SOLN SUPP 8X5XNBD Catalyst 2960-X 24 GigE 2 x 10G SFP+ LAN	Inquiry
